| Produkt | Onderdeelnummer | Aantal |
|---|
| Produkt | Onderdeelnummer | Aantal |
|---|
| Onderdeelnummer | Produkt | Stukprijs Incl. BTW | Aantal | |||
|---|---|---|---|---|---|---|
| # 1 |
54110-29300-000 5411029300000 5411029300000 |
DRUM, FRONT HUB
HUB, WHEEL |
||||
| # 2 |
54112-30500-000 5411230500000 5411230500000 |
FLANGE, FRONT HUB RH
HUB FLANGE, FRONT RH |
||||
| # 3 |
02112-06108-000 02112-06107-0000211206108000 |
SCREW
SCREW FIG.28 (E-5) : GSX1100ESD |
||||
| # 4 |
54151-30500-000 5415130500000 5415130500000 |
RETAINER, FR HUB BEAR
RETAINER, HUB BEARING RH |
||||
| # 5 |
01107-06168-000 01500-06167-0000110706168000 |
BOLT
BOLT, FENDER REAR |
||||
| # 6 |
08321-21068-000 08321-01067-0000832121068000 |
WASHER, LOCK
LOCK WASHER |
||||
| # 7 |
54210-48500-000 5421048500000 |
PANEL, FR HUB
DISCONTINUED |
Niet beschikbaar | |||
| # 8 |
54410-07002-000 54400-07870-0005441007002000 |
SHOE SET, BRAKE
SHOE, BRAKE |
||||
| # 9 |
09443-07001-000 0944307001000 0944307001000 |
SPRING
|
||||
| # 10 |
54441-48500-000 5444148500000 |
BRAKE CAM
DISCONTINUED |
Niet beschikbaar | |||
| # 11 |
09280-14003-000 09280-14011-0000928014003000 |
O RING
|
||||
| # 12 |
09160-14001-000 09160-14055-0000916014001000 |
WASHER, 14.5X22X1.6
WASHER (14.5*22*1.6) |
||||
| # 13 |
54451-32400-000 54451-32401-0005445132400000 |
LEVER, FRONT BRAKE CAM
LEVER, BRAKE CAM |
||||
| # 14 |
01107-06258-000 01500-06257-0000110706258000 |
BOLT
BOLT, RETURN |
||||
| # 15 |
54611-28401-000 54611-28402-0005461128401000 |
SPEEDOMETER GEAR
DISCONTINUED |
||||
| # 16 |
54621-28400-000 54621-28401-0005462128400000 |
SPEEDOMETER PINION
DISCONTINUED |
||||
| # 17 |
54632-01001-000 5463201001000 5463201001000 |
BUSH, SPEEDOMETER GEA
BUSH
|
||||
| # 18 |
09160-05001-000 09160-05001-A050916005001000 |
WASHER, 5.1X9X0.4
THRUST WASHER (6.1X9X0.4) |
||||
| # 19 |
54661-29300-000 5466129300000 5466129300000 |
DRIVER, SPEEDOMETER G
DRIVER |
||||
| # 20 |
09160-18002-000 0916018002000 0916018002000 |
WASHER, THRUST
THRUST WASHER (18.5X24X1) |
||||
| # 21 |
08331-11189-000 08331-3118A-0000833111189000 |
CLIP
CIRCLIP |
||||
| # 22 |
09134-03101-000 09134-03101-A050913403101000 |
SCREW, 3X4.3
SCREW |
||||
| # 23 |
09285-43001-000 09283-43004-0000928543001000 |
OIL SEAL
|
||||
| # 24 |
54711-16503-000 54711-16504-0005471116503000 |
AXLE, FRONT
DISCONTINUED |
||||
| # 25 |
09180-12041-000 0918012041000 0918012041000 |
SPACER
SPACER (12.6X19X52) |
Niet beschikbaar | |||
| # 26 |
54741-41100-000 5474141100000 5474141100000 |
SPACER, FRONT AXLE RH
SPACER (12.2X9X18.5) |
||||
| # 27 |
08322-11128-000 08322-01127-0000832211128000 |
WASHER
WASHER, INNER (12.5*24*2.3) |
||||
| # 28 |
08314-31128-000 08314-3112A-0000831431128000 |
NUT
|
||||
| # 29 |
04111-30308-000 04111-3030A-0000411130308000 |
COTTER PIN
|
||||
| # 30 |
09159-12006-000 0915912006000 0915912006000 |
NUT
|
||||
| # 31 |
08143-62017-000 08143-6201B-0000814362017000 |
BEARING
|
||||
| # 32 |
08123-62017-000 08133-62017-0000812362017000 |
KOYO B1 12X32X10 *
BEARING |
||||
| # 33 |
55100-48500-000 5510048500000 5510048500000 |
TIRE, FRONT (2.75-21)
|
Niet beschikbaar | |||
| # 34 |
55200-16510-000 55200-16511-0005520016510000 |
TUBE
TUBE, INNER (2.75-21) |
||||
| # 35 |
55261-16510-000 55261-14540-0005526116510000 |
PROTECTOR, INNER TUBE
|
||||
| # 36 |
55311-48020-000 5531148020000 5531148020000 |
WHEEL RIM 160X21
PIM, WHEEL (1.60X21) |
||||
| # 37 |
55320-29300-000 5532029300000 5532029300000 |
SPOKE SET, FRONT
SPOKE SET |
