| # 1 |
31800-06G10-000 31800-06G11-0003180006G10000 |
RELAIS
RELAY ASSY, STARTING MOTOR |
||||
| # 2 |
31861-47E00-000 3186147E00000 3186147E00000 |
COVER
|
||||
| # 3 |
09481-30101-000 0948130101000 0948130101000 |
FUSE (30A)
|
||||
| # 4 |
09128-06013-000 0912806013000 0912806013000 |
SCREW
BOLT, STARTING MOTOR (6X8)
|
||||
| # 5 |
32800-10G10-000 32800-10G20-0003280010G10000 |
RECTIFIER ASSY
|
||||
| # 6 |
32830-22H00-000 3283022H00000 3283022H00000 |
BRACKET, RECT FTG
|
||||
| # 7 |
01550-0812A-000 01550-0812B-000015500812A000 |
BOLT
BOLT, RECT FTG BRKT
|
||||
| # 8 |
33410-35F10-000 33410-35F11-0003341035F10000 |
COIL GSX-R750/1000/K2-
COIL ASSY, IGNITION |
||||
| # 9 |
33420-26F10-000 3342026F10000 3342026F10000 |
COIL ASSY, IGNITION
COIL ASSY, IGNITION FRONT |
||||
| # 10 |
33410-22H00-000 3341022H00000 3341022H00000 |
COIL ASSY, IGNITION REAR
|
||||
| # 11 |
33414-22H00-000 3341422H00000 3341422H00000 |
BRACKET, IGNITION COIL
|
||||
| # 12 |
09180-06195-000 0918006195000 0918006195000 |
SPACER 6.4X10X18 (AL)
SPACER, IGNITION FRONT |
||||
| # 13 |
09180-06198-000 0918006198000 0918006198000 |
SPACER 6.2X12X16 (AL
SPACER, IGNITION REAR
|
||||
| # 14 |
09404-06433-000 09404-06036-0000940406433000 |
CLAMP (L80 T:1.0)
CLAMP (L:80) |
||||
| # 15 |
01547-0535A-000 015470535A000 015470535A000 |
BOLT, IGNITION COIL
|
||||
| # 16 |
01550-0625A-000 015500625A000 015500625A000 |
BOLT
BOLT, IGNITION COIL BRKT
|
||||
| # 17 |
33510-20E00-000 3351020E00000 3351020E00000 |
CAP ASSY, SPARK PLUG
|
||||
| # 18 |
33541-47D00-000 3354147D00000 3354147D00000 |
SEAL, SPARK PLUG
|
||||
| # 19 |
33542-38B00-000 3354238B00000 3354238B00000 |
SEAL
SEAL, HIGH TENSION CORD
|
||||
| # 20 |
32920-22H01-000 32920-22H02-0003292022H01000 |
CONTROL UNIT, FI VLR1800/K8
CONTROL, UNIT, FI |
||||
| # 20 |
32920-22H31-000 3292022H31000 3292022H31000 |
CONTROL, UNIT, FI
|
||||
| # 21 |
33960-06G10-000 3396006G10000 3396006G10000 |
FUEL CUT SENSOR ASSY
SENSOR ASSY, FUEL CUT |
||||
| # 22 |
33970-41G00-000 33970-41G01-0003397041G00000 |
ACTUATOR GSX-R1000/K5
ACTUATOR ASSY, EXHAUST CONTROL |
||||
| # 23 |
01560-0625A-000 015600625A000 015600625A000 |
BOLT, ACTUATOR
|
||||
| # 24 |
33652-26E00-000 3365226E00000 3365226E00000 |
PROTECTOR, BATTERY, 20X90X1.0
PROTECTOR (20X80X1.0)
|
||||
| # 25 |
36611-16G00-000 3661116G00000 3661116G00000 |
PROTECTOR
PROTECTOR (28X50X0.13) |
Suzuki INTRUDER
Cilinderinhoud: 1800 cc Jaar: 2010 Model code VLR1800L0(E2)
