| Produkt | Onderdeelnummer | Aantal |
|---|
| Produkt | Onderdeelnummer | Aantal |
|---|
| Onderdeelnummer | Produkt | Stukprijs Incl. BTW | Aantal | |||
|---|---|---|---|---|---|---|
| # 1 |
35710-20A00-000 3571020A00000 |
RR COMB LAMP ASSY
LAMP ASSY, REAR COMBINATION |
Niet beschikbaar | |||
| # 1 |
35720-40A60-000 3572040A60000 3572040A60000 |
LAMP UNIT, REAR COMBINATION
|
Niet beschikbaar | |||
| # 2 |
35718-20A00-000 3571820A00000 |
SOCKET
|
Niet beschikbaar | |||
| # 3 |
09471-12084-000 0947112084000 0947112084000 |
BULB (12V, 23/8W)
|
Niet beschikbaar | |||
| # 4 |
35910-20A00-000 3591020A00000 |
LICENSE PLATE LAMP
LAMP ASSY, LICENSE PLATE |
Niet beschikbaar | |||
| # 5 |
35912-00A10-000 3591200A10000 3591200A10000 |
LICENSE LAMP LENS
LENS
|
Niet beschikbaar | |||
| # 6 |
35913-04A00-000 3591304A00000 3591304A00000 |
GASKET
|
Niet beschikbaar | |||
| # 7 |
09471-12037-000 0947112037000 0947112037000 |
09471-12037-000
.BULB (12V, 8W) |
Niet beschikbaar | |||
| # 8 |
03211-04208-000 03211-04207-0000321104208000 |
SCREW
.TAPPING SCREW |
||||
| # 9 |
35917-20A00-000 3591720A00000 3591720A00000 |
LICENSE LAMP COVER
COVER, LICENSE LAMP
|
Niet beschikbaar | |||
| # 10 |
03241-04165-000 03242-0416B-0000324104165000 |
SCREW
SCREW, FRONT |
||||
| # 11 |
35726-40A00-000 3572640A00000 3572640A00000 |
TAIL LAMP SOCKET
BRACKET, TAIL LAMP |
Niet beschikbaar | |||
| # 12 |
08316-26066-000 08316-10067-0000831626066000 |
NUT
REFLEX REFLECTOR, REAR SIDE |
||||
| # 13 |
35716-40A00-000 3571640A00000 3571640A00000 |
PLATE
PLATE, TAIL LAMP |
Niet beschikbaar | |||
| # 14 |
02112-06166-000 02112-0616A-0000211206166000 |
SCREW
SCREW 6X16 |
||||
| # 15 |
03541-04126-000 03541-0412A-0000354104126000 |
SCREW. REAR
.SCREW. |
||||
| # 16 |
08316-26066-000 08316-10067-0000831626066000 |
NUT
REFLEX REFLECTOR, REAR SIDE |
||||
| # 17 |
35736-40A00-000 3573640A00000 3573640A00000 |
PLATE, RH
|
Niet beschikbaar | |||
| # 18 |
35737-40A00-000 3573740A00000 3573740A00000 |
PLATE, LH
|
Niet beschikbaar | |||
| # 19 |
35927-44110-000 3592744110000 3592744110000 |
PLATE, REAR LICENSE
BRACKET, LICENSE PLATE
|
||||
| # 20 |
02142-06164-000 02142-0616A-0000214206164000 |
SCREW
SCREW, CENTER COVER & FENDER |
||||
| # 21 |
09169-06025-000 09169-06010-0000916906025000 |
WASHER, LOCK
WASHER, INNER |
||||
| # 22 |
08310-11065-000 0831011065000 |
NUT
|
Niet beschikbaar | |||
| # 23 |
09321-08005-000 0932108005000 0932108005000 |
CUSHION
|
||||
| # 24 |
35950-14A50-000 3595014A50000 3595014A50000 |
REFLEX REFLECTOR, REAR SIDE
|
Niet beschikbaar | |||
| # 25 |
08316-16056-000 08316-1005B-0000831616056000 |
NUT
|
||||
| # 26 |
35975-40A00-000 3597540A00000 3597540A00000 |
BRACKET, RH
|
Niet beschikbaar | |||
| # 27 |
35976-40A00-000 3597640A00000 3597640A00000 |
BRACKET, LH
|
Niet beschikbaar | |||
| # 28 |
02142-05107-000 0214205107000 0214205107000 |
--> 02142-0510A
SCREW
|
