| Produkt | Onderdeelnummer | Aantal |
|---|
| Produkt | Onderdeelnummer | Aantal |
|---|
| Onderdeelnummer | Produkt | Stukprijs Incl. BTW | Aantal | |||
|---|---|---|---|---|---|---|
| # 1 |
45100-46E00-58R 4510046E0058R 4510046E0058R |
SEAT GSX-R1100 WP
SEAT ASSY (BLACK) |
Niet beschikbaar | |||
| # 2 |
09321-10011-000 0932110011000 0932110011000 |
CUSHION
|
||||
| # 3 |
45300-46E00-58R 4530046E0058R 4530046E0058R |
PILLION SEAT
SEAT ASSY, PILLION (BLACK) (NO SEAT BAND) |
Niet beschikbaar | |||
| # 3 |
45300-46E10-58R 4530046E1058R 4530046E1058R |
SEAT ASSY, PILLION (BLACK)
|
Niet beschikbaar | |||
| # 4 |
45321-46E00-000 4532146E00000 4532146E00000 |
PLATE, SEAT LOCK
|
Niet beschikbaar | |||
| # 5 |
45149-31300-000 4514931300000 4514931300000 |
CUSHION
|
||||
| # 6 |
45180-46E00-58R 4518046E0058R 4518046E0058R |
BAND COMP, SEAT
BAND, SEAT GRIP (BLACK) |
||||
| # 7 |
45215-06B00-000 45215-06B01-0004521506B00000 |
CUSHION
|
||||
| # 8 |
45216-06B00-000 4521606B00000 4521606B00000 |
SPACER
|
||||
| # 9 |
08316-10063-000 08319-31067-0000831610063000 |
NUT 6MM
NUT |
||||
| # 10 |
45119-17E00-000 4511917E00000 4511917E00000 |
PLATE, SEAT FRONT HOOK
PLATE, SEAT FRONT |
||||
| # 11 |
09139-06081-000 09122-66007-0000913906081000 |
SCREW, 6X14
DISCONTINUED |
||||
| # 12 |
09139-06027-000 0913906027000 0913906027000 |
SCREW
SCREW, PILLION SEAT (6X12)
|
||||
| # 13 |
45149-04A00-000 4514904A00000 4514904A00000 |
UPPER CUSHION
CUSHION, SEAT SUPPORT
|
||||
| # 14 |
45220-46E00-000 4522046E00000 4522046E00000 |
BRKT COMP, SEAT SPRT, RR
BRACKET, SEAT SUPPORT REAR |
||||
| # 15 |
45280-46E00-000 4528046E00000 4528046E00000 |
SEAT LOCK CABLE
CABLE, SEAT LOCK |
Niet beschikbaar | |||
| # 16 |
02122-06253-000 02122-0625B-0000212206253000 |
SCREW
|
||||
| # 17 |
09407-18403-000 09407-18402-0000940718403000 |
CLAMP, L:165
CLAMP, BREATHER TUBE (L:165) |
||||
| # 18 |
95700-12852-000 95700-12853-0009570012852000 |
LOCK SET, SEAT
|
||||
| # 19 |
45289-45D01-000 4528945D01000 4528945D01000 |
PLATE, SEAT LOCK GUARD
|
||||
| # 20 |
09139-06075-000 0913906075000 0913906075000 |
SCREW (6X12)
|
||||
| # 21 |
09816-00103-000 0981600103000 0981600103000 |
SPANNER, 4, HEXAGON
SPANNER, HEXAGON 4 |
||||
| # 22 |
46211-46E00-0JW 46211-46E00-33J4621146E000JW |
PILLION RIDER HANDLE
HANDLE, PILLION RIDER (WHITE) |
||||
| # 22 |
46211-46E00-17U 4621146E0017U 4621146E0017U |
HANDLE, PILLION RIDER (GRAY)
|
Niet beschikbaar | |||
| # 22 |
46211-46E00-35W 4621146E0035W 4621146E0035W |
HANDLE, PILLION RIDER (GRAY)
|
Niet beschikbaar | |||
| # 23 |
09250-06004-000 0925006004000 0925006004000 |
CAP
|
||||
| # 24 |
07130-08653-000 07130-0865B-0000713008653000 |
BOLT
|
||||
| # 25 |
46238-46E00-000 4623846E00000 4623846E00000 |
CUSHION, PILLION RIDE
CUSHION, RH |
Niet beschikbaar | |||
| # 26 |
46239-46E00-000 4623946E00000 4623946E00000 |
CUSHION, PILLION RIDE
CUSHION, LH |
Niet beschikbaar | |||
| # 27 |
09180-08180-000 0918008180000 |
SPACER
|
Niet beschikbaar | |||
| # 28 |
45500-46810-0JW 45500468100JW 45500468100JW |
SEAT TAIL BOX SET
DISCONTINUED |
Niet beschikbaar | |||
| # 28 |
45500-46810-17U 455004681017U 455004681017U |
DISCONTINUED
|
Niet beschikbaar | |||
| # 28 |
45500-46810-33J 455004681033J 455004681033J |
SEAT TAIL BOX SET
DISCONTINUED |
Niet beschikbaar | |||
| # 28 |
45500-46810-35W 455004681035W 455004681035W |
BOX SET, SEAT TAIL (GRAY)
|
Niet beschikbaar | |||
| # 29 |
46220-46E00-58R 4622046E0058R 4622046E0058R |
SEAT BACKREST
BACKREST, SEAT (BLACK) |
||||
| # 30 |
09320-12031-000 0932012031000 0932012031000 |
CUSHION
|
||||
| # 31 |
45591-12C00-000 4559112C00000 4559112C00000 |
PROTECTOR
|
Niet beschikbaar | |||
| # 32 |
09139-06067-000 09139-06237-0000913906067000 |
BOLT
|
||||
| # 33 |
09160-06066-000 0916006066000 0916006066000 |
WASHER
|
||||
| # 34 |
45149-31300-000 4514931300000 4514931300000 |
CUSHION
|
