| Produkt | Onderdeelnummer | Aantal |
|---|
| Produkt | Onderdeelnummer | Aantal |
|---|
| Onderdeelnummer | Produkt | Stukprijs Incl. BTW | Aantal | |||
|---|---|---|---|---|---|---|
| # 1 |
51410-41F50-000 5141041F50000 5141041F50000 |
STEM, STEERING
|
||||
| # 1 |
51410-41F60-000 5141041F60000 5141041F60000 |
STEM, STEERING
|
||||
| # 2 |
51644-12C00-000 5164412C00000 5164412C00000 |
SEAL
SEAL, STEERING LOWER
|
||||
| # 3 |
09267-30010-000 0926730010000 0926730010000 |
BEARING
BEARING (30X55X17)
|
||||
| # 4 |
07130-1030B-000 071301030B000 071301030B000 |
BOLT
BOLT, STEM
|
||||
| # 5 |
09267-25009-000 0926725009000 0926725009000 |
BEARING
BEARING (25X47X15)
|
||||
| # 6 |
51631-28000-000 5163128000000 5163128000000 |
NUT, STEERING STEM
NUT, STEM
|
||||
| # 7 |
51643-40502-000 51643-40503-0005164340502000 |
DUST SEAL, STEERING UPPER
SEAL, DUST UPPER
|
||||
| # 8 |
51356-24B01-000 5135624B01000 5135624B01000 |
WASHER
WASHER, STEM
|
||||
| # 9 |
51353-24B00-000 5135324B00000 5135324B00000 |
NUT
NUT, STEM
|
||||
| # 10 |
51311-41F40-000 5131141F40000 5131141F40000 |
STEERING STEM HEAD
HEAD, STEERING STEM |
||||
| # 10 |
51311-41F60-000 5131141F60000 5131141F60000 |
HEAD, STEERING STEM
|
||||
| # 11 |
51321-06G00-000 5132106G00000 5132106G00000 |
BOLT
|
||||
| # 12 |
09250-06009-000 0925006009000 0925006009000 |
CAP
CAP, BOLT |
||||
| # 12 |
09250-06011-000 0925006011000 0925006011000 |
CAP
CAP, BOLT
|
||||
| # 13 |
51321-10F00-000 5132110F00000 5132110F00000 |
BOLT, HANDLE HOLDER, 07130-08307
BOLT, HOLDER |
||||
| # 14 |
09164-08015-000 0916408015000 0916408015000 |
WASHER
|
||||
| # 15 |
56211-41F20-000 5621141F20000 5621141F20000 |
UPPER HOLDER
HOLDER, HANDLE UPPER |
||||
| # 16 |
56221-41F20-000 5622141F20000 5622141F20000 |
LOWER HOLDER
HOLDER, HANDLE LOWER |
||||
| # 17 |
51226-41F20-000 5122641F20000 5122641F20000 |
BOLT
BOLT, STAY |
||||
| # 18 |
56240-41F20-000 5624041F20000 5624041F20000 |
DAMPER
DAMPER, RUBBER |
||||
| # 19 |
56245-41F20-000 5624541F20000 5624541F20000 |
SEAT RUBBER
|
||||
| # 20 |
51354-41F20-000 5135441F20000 5135441F20000 |
WASHER
|
||||
| # 21 |
56246-41F20-000 5624641F20000 5624641F20000 |
NUT
|
||||
| # 22 |
51530-41F20-000 5153041F20000 5153041F20000 |
RH UPPER COVER
COVER, UPPER, R |
||||
| # 23 |
51540-41F20-000 5154041F20000 5154041F20000 |
LH UPPER COVER
COVER, UPPER, L |
||||
| # 24 |
51468-10F00-000 5146810F00000 5146810F00000 |
SEAT
SEAT, RUBBER |
||||
| # 25 |
51467-10F00-000 5146710F00000 5146710F00000 |
WASHER
|
||||
| # 26 |
68281-35F00-000 6828135F00000 6828135F00000 |
EMBLEM, S
EMBLEM, "S"
|
